Locking collar and synchro-hub for synchromeshed gear for 7th
and 5th gears
2.4 Dismantling and assembling output
shaft 3
⇒ “2.4.1 Dismantling output shaft 3”, page 145
⇒ “2.4.2 Assembling output shaft 3”, page 147
⇒ “2.4.3 Dismantling and assembling locking collar and synchro-
hub of output shaft 3”, page 148
2.4.1 Dismantling output shaft 3
Press off bearing of output shaft 3.
– First destroy cage of bearing.
– Press off bearing inner race.
Note
Shaft will fall out downwards! Therefore, position suitable items
under press. It is also possible to hold shaft by hand.
Golf 2013 ➤
7-speed dual clutch gearbox 0CW - Edition 10.2012
2. Output shaft 145
