Mechatronic unit for dual clutch gearbox -J743- - specified torque
and tightening sequence
Note
Always renew after removing.
– Tighten bolts in 4 stages as follows:
Stage Bolts Specified torque
1 -A- Screw in to contact by hand.
2 Remove guide
bolts -T10406- .
3 -B- Screw in to contact by hand.
4 -A, B- Tighten to 10 Nm in diagonal se‐
quence.
Component Specified torque
Engaging lever cover 8 Nm
1.2 Removing and installing mechatronic
unit for dual clutch gearbox -J743-
Special tools and workshop equipment required
♦ Vehicle diagnostic tester
♦ Used oil collection and extraction unit -V.A.G 1782-
♦ Engine bung set -VAS 6122- ; alternatively sealing cap -0AM
325 120 A-
Golf 2013 ➤
7-speed dual clutch gearbox 0CW - Edition 10.2012
42 Rep. gr.34 - Controls, housing
