– Turn clutch by hand. It should be possible to turn it without
difficulty.
Note
♦ If the clutch is difficult to turn or if the clutch lining is being
rubbed hard, remove clutch again ⇒ page 12 .
♦ Check installation position of shims -arrows-.
♦ The shims must be properly seated and must not be damaged.
♦ A mathematical error could have been made. Check meas‐
urements again ⇒ page 29
♦ If no fault can be found, the clutch may have been moved out
of position due to transport/assembly and a new clutch now
has to be installed. The position of the engagement bearings
must then be readjusted ⇒ page 29 .
– Remove two plugs and put breather caps -arrows-on.
Note
The breather cap on the mechatronic unit is destroyed during re‐
moval and must be renewed.
– Dispose of excess shims.
– After installing the gearbox, use the vehicle diagnostic tester
to run the Basic setting complete function in Guided
Functions .
1.4 Renewing input shaft seal
Special tools and workshop equipment required
Golf 2013 ➤
7-speed dual clutch gearbox 0CW - Edition 10.2012
20 Rep. gr.30 - Clutch
