30 – Clutch
1 Clutch
⇒ “1.1 Assembly overview - dual clutch”, page 11
⇒ “1.2 Removing dual clutch”, page 12
⇒ “1.3 Installing dual clutch”, page 16
⇒ “1.4 Renewing input shaft seal”, page 20
⇒ “1.5 Renewing oil seal for inner input shaft”, page 22
1.1 Assembly overview - dual clutch
1 - Hinge mounting
❑ For large engaging lever
“K 1”
❑ Cannot be renewed.
2 - Ball pin
❑ Small small engaging
lever “K 2”
❑ Removing and installing
⇒ page 30 .
3 - Shim “SK 1”
❑ Determining thickness
⇒ page 29
4 - Shim “SK 2”
❑ Determining thickness
⇒ page 29
5 - Small engagement bear‐
ings for “K 2”
6 - Dual clutch
❑ Removing and installing
⇒ page 11 .
7 - Retaining ring
❑ Renew.
8 - Hub
9 - Retaining ring
❑ Renew.
10 - Large engaging lever for
“K 1”
❑ With engagement bear‐
ing
❑ Removing and installing
⇒ page 26 .
11 - Upper section of bushing
❑ Small small engaging lever “K 2”
❑ Is removed and installed together with small engaging lever and lower section of bushing
12 - Small engaging lever for “K 2”
❑ Is removed and installed together with upper and lower section of bushing
❑ Removing and installing ⇒ page 26 .
Golf 2013 ➤
7-speed dual clutch gearbox 0CW - Edition 10.2012
1. Clutch 11
