6 - T-piece
❑ Distribution of washer fluid line to washer jets
7 - Angled piece
8 - Headlight washer system pump -V11-
❑ Removing and installing ⇒ page 208
9 - Windscreen washer and headlight washer system reservoir
❑ Removing and installing ⇒ page 195
10 - Filler pipe of reservoir for windscreen washer and headlight washer systems
❑ Removing and installing ⇒ page 195
Not illustrated
Pop-up spray jet cylinder to front bumper cover - 4.5 Nm
5.2 Removing and installing headlight
washer system pump -V11-
The headlight washer system pump -V11- is mounted on the
washer fluid reservoir in the right-hand wheel housing.
Caution
♦ Switch off ignition and all electrical consumers.
♦ Remove the ignition key.
Removing
– Remove front bumper cover ⇒ General body repairs, exterior;
Rep. gr. 63 .
– Pull headlight washer pump -V11- -9- upwards out of reservoir.
– Disconnect connector -10-.
– To remove the connecting pipe -8-, pull out securing clip and
pull connecting pipe -8- off headlight washer system pump -
V11- .
Installing
Install in the reverse order of removal. When doing this, note the
following:
– Tighten all threaded connections to specified torques
⇒ page 207 .
– On completion of installation work, bleed headlight washer
system ⇒ page 210 .
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
208 Rep. gr.92 - Windscreen wash/wipe system
