14 - Bolt
❑ 4 Nm
15 - Left gas discharge bulb control unit -J343- / right gas discharge bulb control unit -J344-
❑ Not capable of self-diagnosis
❑ Removing and installing ⇒ page 271
16 - Bolt
❑ 2 Nm
17 - Left headlight main beam bulb -M30- / right headlight main beam bulb -M32-
❑ Bulb: H7U 12 V/55 W
❑ Renewing ⇒ page 264
18 - Front left turn signal bulb -M5- / front right turn signal bulb -M7-
❑ Bulb: H2 WLL 12 V/21 W
❑ Renewing ⇒ page 267
19 - Left side light bulb -M1- / right side light bulb -M3-
❑ Bulb: W 12 V/5 W
❑ Renewing ⇒ page 266
20 - Cover cap
21 - Cover cap
3.3 Removing and installing headlight
Removing and installing headlights ⇒ page 215 .
Observe safety notes for gas discharge bulbs ⇒ page 258 .
3.4 Adjusting headlight installation position
Adjusting headlight installation position ⇒ page 217 .
3.5 Renewing bulbs
3.5.1 Renewing gas discharge bulb
Note
The diagrams show renewal of left gas discharge (xenon) bulb -
L13- for the left headlight.
Caution
♦ Switch off ignition and all electrical consumers.
♦ Remove the ignition key.
♦ Observe safety notes for gas discharge bulbs
⇒ page 258 .
Removing
– Remove headlight ⇒ page 262 .
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
262 Rep. gr.94 - Lights, bulbs, switches - exterior
