9 Tail lights
9.1 Assembly overview - tail light in side panel (bulbs) - saloon
1 - Nut
❑ 3.5 Nm
2 - Left brake light bulb -M9- /
right brake light bulb -M10-
3 - Tail light housing in side
panel
❑ Contains LED module
for daytime running light
and side light
❑ Removing and installing
⇒ page 307
4 - Rear left turn signal bulb -
M6- / rear right turn signal bulb
-M8-
5 - Bulb carrier
❑ Removing and installing
⇒ page 308
9.2 Removing and installing tail light in side
panel (bulbs) - saloon
Caution
♦ Switch off ignition and all electrical consumers.
♦ Remove the ignition key.
Removing
– Push side panel trim to the side.
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
9. Tail lights 307
