– Unscrew the three bolts -arrows-.
Note
When right power output module for headlight -J668- is pulled off
from headlight housing, electrical connectors are simultaneously
disconnected.
– Pull right power output module for headlight -J668- -1- at right
angles out of headlight housing.
Installing
Carry out installation in the reverse sequence, noting the follow‐
ing:
Caution
When installing right power output module for headlight -
J668- , ensure that the seal is seated correctly. The ingress of
water will lead to permanent damage to the headlight.
– Tighten all threaded connections to specified torques
⇒ page 279 .
Note
Control unit for headlight range control -J431- must be recoded if
a new power output module for right headlight -J668- is installed
⇒ page 291 . Then subsequently perform the basic setting of
headlights ⇒ Maintenance ; Booklet 20.1 ; Descriptions of work .
– Check headlight functions.
4.7.2 Checking power output module for
headlight
Special tools and workshop equipment required
♦ Vehicle diagnosis, testing and information system -VAS
5051B-
The following procedure enables you to test the power output
module for left headlight -J667- / power output module for right
headlight -J668- .
Procedure
– Connect vehicle diagnosis, testing and information system -
VAS 5051B- .
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
4. Headlights with gas discharge bulbs and cornering lights (from MY2010) 289
