– Insert ignition key in lock cylinder and turn to position „Drive“.
Note
The key must be in the „Drive“ position.
Positions for key in lock cylinder:
1 - Position „Stop“
2 - Position „Drive“
3 - Position „Start“
– Install all parts in reverse order of removal.
13.3.1 Removing and installing ignition key
withdrawal lock solenoid -N376-
The ignition key withdrawal lock solenoid -N376- is located very
close to the ignition starter key.
Note
To remove ignition key on vehicles with an automatic gearbox,
always move selector lever to position „P“ first then switch off ig‐
nition. Otherwise the ignition key withdrawal lock solenoid -N376-
will inhibit the removal of the ignition key.
Removing
– Remove steering column electronics control unit -J527-
⇒ page 321 .
– Release fastener -2- using a suitable screwdriver.
– Pull ignition key withdrawal lock solenoid -N376- -1- in direc‐
tion of arrow and out of its mounting.
– The electrical connection will be disconnected automatically.
Installing
– Carry out installation in the reverse sequence, noting the fol‐
lowing:
Note
After reconnecting the battery -A- , carry out final control diagno‐
sis to activate ignition key withdrawal lock solenoid -N376-
⇒ page 328 .
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
13. Ignition/starter switch and lock cylinder 333
