– Push connectors -4- in until they can be heard to engage in
holding cage -2-.
Pin assignment of trailer socket -U10-
1 - Terminal LTS (left turn signal)
2 - Terminal NSL (rear fog lamp)
3 - Terminal 31
4 - Terminal RTS (right turn signal)
5 - Terminal 58R (right tail light)
6 - Terminal 54 (brake light)
7 - Klemme 58L (left tail light)
8 - Terminal RF (reversing light)
9 - Terminal 15
10 - Reserved for terminal 30
11 - Reserved for terminal 31
12 - Not assigned
13 - Terminal 31
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
17. Removing and installing trailer socket U10 381
