9-26 Phaser 3300MFP Service Manual
Parts List
Parts List 12.0 Cover Platen Assembly
ID No. Name/Description
Part Number
0 MEA-COVER PLATEN —
1 MEA-TX STACKER 022N02311
1-1 COVER-M_STACKER TX —
1-2 GUIDE-M_DOCU L —
1-3 GUIDE-M_DOCU R —
1-4 IPR-WASHER SPRING CU —
1-5 GEAR-PINION —
2 COVER-M_PLATEN 002N02651
3 SHEET-WHITE SPONGE 095N00274
4 MEA UNIT-HINGE 003N01018
5 SPRING ETC-FEED 009N01489
6 ICT-SHAFT PINCH 006N01218
7 PMO-ROLL PINCH 022N02014
8 SHAFT-IDLE FEED 006N01302
9 ROLLER-ADF FEED 022N02312
