10-8 Phaser 3300MFP Service Manual
Wiring Diagrams
Control Board Connector Locations
s3300mfp-102
Modem PBA
Duplex Motor
Engine (HVPS)
BLDG
(Main Motor)
Pick Up Clutch
REGI Clutch
MPF Clutch
MPF_SEN
Thermistor
LSU
LSU_5V
Cartridge
(CRUM)
USB Host
Control Panel
CCD
Flat Motor
Flat Cover
ADF
Network
Port
USB
Port
SCF Con
(Tray 2)
SDRAM
CN4 CN1 CN2
CN5
CN3
CN6
CN7
CN8
CN9
CN12
CN14
CN15
CN17
CN18
CN23
CN24
CN26
CN27
CN22
CN25
CN16
CN13
