Phaser 3300MFP Service Manual 10-15
Wiring Diagrams
Control Board to Fuser, CCD
Control
Board
s3300mfp-181
Fuser
1
2
Thermistor-1
CN12
Thermistor-2
+5VDC
+3.3VDC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
CN5
CN
CCD
B_Vin
G_Vin
R_Vin
Dout4+
Dout4-
Dout1-
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
+24VDC
Scanner_DPI_Control
Scanner_BW_Control
Scanner_PI_TG1
+24VDC
+5VDC
+3.3VDC
Dout1+
Dout2+
Dout2-
Dout3+
GND
GND
GND
Dout3-
INV_Power
GND
GND
GND
