Status Indicator RAPs
WorkCentre 3119 07/06 2-9
5 Multi-Feeding RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
Multiple sheets of paper are fed together.
Check and Cause Solution
1. Ensure that the paper size guides, PL 9 are
set correctly.
1. Adjust the paper guides, PL 9.
2. The RPR-friction pad and/or IPR plate, PL
9 is contaminated with foreign matter (e.g oil).
2. Clean with soft cloth dampened with IPA
(Isopropyl Alcohol) or water.
Install new parts as necessary:
• RPR-friction pad, PL 9
• IPR plate, PL 9
3. Paper has a rough surface texture 3. Use paper with a smoother surface finish.
4. Check the solenoid HB (pickup) operation
using Engine Test Mode, GP 4.
4. Install new parts as necessary:
• Solenoid HB (Pickup), PL 3
• Main PBA, PL 1
To Next Page
