Status Indicator RAPs
2-14 07/06 WorkCentre 3119
10 Melting Fuser Gear RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
Constant Jam when paper enters the Fuser unit.
The Fuser rollers do not turn.
Check and Cause Solution
1. Problem caused due to an overheated
machine.
Check the following parts:
• Halogen lamp, PL 5
• Thermostat, PL 5
• Thermistor, PL 5
• Fuser gears, PL 5
1. Check the fuser operation using Engine
Test Mode, GP 4.
Install new parts as necessary:
• Halogen lamp, PL 5
• Thermostat, PL 5
• Thermistor, PL 5
•Fuser, PL 5
• SMPS/HVPS, PL 1
• Main PBA, PL 1
To Next Page
