Image Quality
3-16 06/06 WorkCentre 3119
IQ 14 Contamination on Back of Page
Description
The back of the page is contaminated at 45.3mm or 75.3mm intervals.
Check and Cause Solution
1. 45.3mm: Transfer roller, PL 1, is
contaminated.
1. Run Clean Drum, GP 3 several
times. Install a new transfer roller, PL
1 if necessary
2. 75.3mm: Pressure roller, PL 5, is
contaminated.
CAUTION
Take care not to bend or break the
thermistor.
3. Disassemble the fuser, GP 9.
Clean the heat roller, pressure roller,
and thermistor, PL 5. If necessary
install a new fuser, PL 1.
To Next Page
