Status Indicator RAPs
2-10 07/06 WorkCentre 3119
6 Fuser Jam RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
Paper rolled around fuser rollers or ‘Concertina’ jam.
Check and Cause Solution
1. Contamination of the pressure roller or heat
roller, PL 5.
1. Disassemble the fuser, REP 9 and clean
the surfaces of the rollers with IPA or water.
Clean the contamination between the heat
roller and thermistor, PL 5.
2. Damaged stripper fingers or stripper finger
springs, PL 5.
2. Check the stripper fingers for damage.
Install a new fuser, PL 5 if necessary.
To Next Page
