Xerox WorkCentre 5222 User Manual

February, 2008
4-224
WorkCentre 5225, 5230
ADJ 9.1.1
Launch Version
Repairs and Adjustments
Adjustment
1. Access Diagnostic Routines.
a. Enter UI Diagnostics (UI Diagnostic Mode).
2. Select NVM Read/Write.
3. Adjust the measured values of the Lead (A) and Side Edges (B) using the following NVM
so that the measured values fall within the specifications of the respective supporting
modes.
If the measured value is shorter than specification above (A or B): Set a larger value.
If the measured value is longer than specification above (A or B): Set a smaller value.
• Adjustment of A (Lead Edge), refer to Table 3 below.
• Adjustment of B (Side Edge), refer to Table 4 below.
4. After adjustment, print the test pattern in the same mode and measure the Lead and Side
Edge values. Repeat this procedure until the values fall within the specifications.
5. Repeat the procedure until the measured values of the Lead (A) and Side Edges (B) fall
within the specifications.
Table 3 NVM List of Lead Edge
Chain Link Name Min.
Initia
l
Max Increment
742-027 LEAD REGI ADJUSTMENT - ALL TRAY 0 33 66 0.2175mm
760-001 TRAY1 for Normal Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-002 TRAY2-4 for Normal Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-003 MPT for Normal Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-005 DUP ALL SIZE for Normal Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
760-013 DUP A3 Group - LEAD REGI ADJUST-
MENT
0 10 16 0.363mm
760-014 DUP A4S Group - LEAD REGI ADJUST-
MENT
0 10 16 0.363mm
760-015 DUP A4L Group - LEAD REGI ADJUST-
MENT
0 10 16 0.363mm
760-016 TRAY1 for Thick-1 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-017 TRAY1 for Thick-2 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-018 TRAY2-4 for Thick-1 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-019 TRAY2-4 for Thick-2 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-020 MPT for Thick-1 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-021 MPT for Thick-2 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-022 DUP ALL SIZE for Thick-1 Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
760-023 DUP ALL SIZE for Thick-2 Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
760-24 Tray 2-=4, HCF for Thick-1 Paper-REGI
LOOP TIMER
0 33 66 0.363mm
760-25 Tray3-4, HCF for Thick-2 Paper-REGI
LOOP TIMER
0 33 66 0.363mm
760-031 TRAY1 for Thick-4 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-032 TRAY2-4 for Thick-4 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-033 MPT for Thick-4 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-034 DUP ALL SIZE for Thick-4 Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
Table 4 NVM List of Side Edge
Chain Link Name Min.
Initia
l
Max Increment
749-001 ALL TRAY-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-002 TRAY1-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-003 TRAY2-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-004 TRAY3-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-005 TRAY4-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-007 MPT-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-009 DUP ALL TRAY-LASER SIDE REGI
ADJUSTMENT
1 50 99 0.254mm
749-010 DUP TRAY1-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-011 DUP TRAY2-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-012 DUP TRAY3-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-013 DUP TRAY4-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-015 DUP MPT-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
Table 3 NVM List of Lead Edge
Chain Link Name Min.
Initia
l Max Increment

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
