Xerox WorkCentre 5222 User Manual

February, 2008
2-562
WorkCentre 5225, 5230
078-940, 078-941
Launch Version
Status Indicator Raps
078-940 HCF Paper Misfeed RAP
BSD-ON:8.9
There is a problem with one of the following:
• HCF Lift, Lift Motor
• HCF Feed Motor
Procedure
Enter Component Control [078-003 or 004 Tray 6 Feed/Lift Motor ON]. The Tray 6 Feed/Lift
Motor (PL 18.4) can be heard (the lifted paper plate drops when the tray is opened).
YN
Check the connections of JF57 and JF06. JF57 and JF06 are connected correctly.
YN
Connect JF57 and JF06.
Check the wire-wound resistance of Tray 6 Takeaway Motor is approx. 0.8 ohms at the mea-
surement points below.
• JF57-3 to pins 1/2
• JF57-4 to pins 5/6
If OK, go to 8.9 BSD and troubleshoot the Tray 6 Takeaway Motor circuit.
Execute Component Control [078-101 Tray 6 Feed Out Sensor]. Move the actuator of the Tray
6 Feed Out Sensor.
The display changes.
YN
Go to 8.9 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Feed Out Sensor PF67-2 to HCF PWB PF01-2
• Tray 6 Feed Out Sensor PF67-1 to HCF PWB PF01-3
• Tray 6 Feed Out Sensor PF67-3 to HCF PWB PF01-1
If OK, replace the Tray 6 Feed Out Sensor (PL 18.7) then the HCF PWB (PL 18.8).
Check the HCF paper lift components and repair as required (PL 18.2, PL 18.3).
078-941 HCF Paper Tray Size Mismatch RAP
BSD-ON:7.15
HCF Paper Size Mismatch.
Initial Actions
Use recommended paper sizes
Procedure
Check connectors JF01, PF/JF51, PF/JF52, and PF/JF53 are connected correctly. The
connectors are connected correctly.
YN
Connect JF01, PF/JF51, PF/JF52, and PF/JF53.
Enter Component Control [078-202, Tray 6 Size Sensor (Letter)]. Actuate the sensor with a
piece of paper.
The display changes.
YN
Go to 7.15 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Size Sensor (Letter) Sensor JF51-2 to HCF PWB JF01-11
• Tray 6 Size Sensor (Letter) Sensor PF51-3 to HCF PWB JF01-12
• Tray 6 Size Sensor (Letter) Sensor PF51-1 to HCF PWB JF01-10
If OK, replace the Tray 6 Size Sensor (PL 18.8) then the HCF PWB (PL 18.8).
Component Control [078-203, Tray 6 Size Sensor (A3)]. Actuate the sensor with a piece of
paper.
The display changes.
YN
Go to 7.15 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Size Sensor (A3) Sensor JF52-2 to HCF PWB JF01-8
• Tray 6 Size Sensor (A3) Sensor JF52-3 to HCF PWB JF01-9
• Tray 6 Size Sensor (A3) Sensor JF52-1 to HCF PWB JF01-7
If OK, replace the Tray 6 Size Sensor (PL 18.8) then the HCF PWB (PL 18.8).
Component Control [078-204, Tray 6 In Sensor]. Actuate the sensor with a piece of paper.
The display changes.
YN
Go to 7.15 BSD and check the following for an open wire, short or poor contact:
• Tray 6 Size Sensor (A3) Sensor JF53-2 to HCF PWB JF01-5
• Tray 6 Size Sensor (A3) Sensor JF53-3 to HCF PWB JF01-6
• Tray 6 Size Sensor (A3) Sensor JF53-1 to HCF PWB JF01-4
If OK, replace the Tray 6 In Sensor (PL 18.1) then the HCF PWB (PL 18.8).
Ensure the paper guilds are adjusted correctly to the paper size.

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
