February, 2008
2-514
WorkCentre 5225, 5230
062-357, 062-360
Launch Version
Status Indicator Raps
062-357 CCD Fan Failure RAP
CCD Fan Failure
Initial Actions
• Check the vent has no foreign object and is not clogged.
• Check there is no dust on the Fan Blade.
Procedure
Remove the Platen Glass. Execute Component Control [062-017 CCD Fan]. The CCD Fan
operates.
YN
Replace the CCD Fan (PL 6.4).
Check CCD Fan connections and wiring for damage.
062-360 Carriage Position RAP
BSD-ON: 6.3
• An error occurred while counting the pulses of the Carriage Motor.
• After the Carriage Motor turned On, the IIT Registration Sensor did not turn On within the spec-
ified time.
Procedure
Check the Carriage Rail for dirt or contamination or distortion. Dirt or contamination or distor-
tion is found in the Carriage Rail.
YN
Clean the rails or correct the distortion (PL 11.4).
Execute Component Control [062-212 IIT Registration Sensor]. Actuate the IIT Registration
Sensor with paper. The display changes.
YN
Check the connections of P/J728 and P/J7193. P/J728 and P/J7193 are connected
correctly.
YN
Connect P/J728 and P/J7193.
Check the wire between J728 and J7193 for an open circuit or a short circuit (BSD 6.3
Flag 2/Flag 3).
The wire between J728 and J7193 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the IIT/IPS PWB P7193-B10 (+) and GND (-) (BSD 6.3 Flag
2/Flag 3).
The voltage is approx. +5VDC.
YN
Replace the IIT/IPS PWB (PL 11.3).
Measure the voltage between the IIT/IPS PWB P7193-B12 (+) and GND (-) (BSD 6.3 Flag
2).
Actuate the IIT Registration Sensor (PL 11.4) with paper. The voltage changes.
YN
Replace the IIT Registration Sensor (PL 11.4).
Replace the IIT/IPS PWB (PL 11.3).
Alternately execute Component Control[062-005 Carriage Motor SCAN ON] and Component
Control[062-006 Carriage Motor RETURN ON].
The Carriage Motor starts up.
YN
Check the connection P/J721. P/J721 is connected correctly.
YN
Connect P/J721.
Check the wires on J721 for an open circuit or a short circuit (BSD 6.3 Flag 1). The
wires on J721 are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
A B

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
