Xerox WorkCentre 5222 User Manual

February, 2008
2-96
WorkCentre 5225, 5230
010-398, 010-420
Launch Version
Status Indicator Raps
010-398 Fuser Lock Failure RAP
BSD-ON:10.2
The Fuser Fan failed.
Initial Actions
• Power OFF/ON
• Clear away foreign substances and dust accumulated at the exhaust.
Procedure
Turn on the power.
Visually check the rotation of the Fuser Fan. The Fuser Fan is rotating.
YN
Measure the voltage between the MCU PWB P/J408-2 (+) and GND (-) (BSD 10.2 Flag
1).
The voltage is approx. +24VDC.
YN
Replace the MCU PWB (PL 9.1).
Check the wire between P/J214-13 and P/J408-2 for an open circuit or a short circuit
(BSD 10.2 Flag 1).
The wire between J214-13 and J408-2 is conducting without an
open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Main Drive Assembly CN102-3 (+) and CN102-2 (-)
(BSD 10. 2 Flag 2).
The voltage is +24VDC.
YN
Replace the Main Drive Assembly (PL 1.1).
Replace the Fuser Fan (PL 4.2).
Measure the voltage between the MCU PWB P/J408-1 (+) and GND (-) (BSD 10.2 Flag 4).
The voltage is approx. 0VDC.
YN
Measure the voltage between the Main Drive Assembly CN102-1 (+) and GND (-) (BSD
10.2 Flag 2).
The voltage is approx. 0VDC.
YN
Replace the Fuser Fan (PL 4.2).
Check the wire between P/J214-14 and P/J408-1 for an open circuit or a short circuit
(BSD 10.2 Flag 4).
The wire between J214-14 and J408-1 is conducting without an
open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Main Drive Assembly (PL 1.1).
Replace the MCU PWB (PL 9.1).
010-420 Fuser Near end of life RAP
BSD-ON:10.3
The Fuser is near end of life.
Initial Actions
• Power Off/On
Procedure
Turn on the power.
Visually check the rotation of the Fuser Fan. The Fuser Fan is rotating.
YN
Measure the voltage between the MCU PWB P/J408-2 (+) and GND (-) (BSD 10.2 Flag
1).
The voltage is approx. +24VDC.
YN
Replace the MCU PWB (PL 9.1).
Check the wires between MCU PWB and the Fuser Fan for an open or a short circuit
(BSD 10.2 Flag 1/Flag 2/Flag 3/Flag 4).
The wires between MCU PWB and the Fuser
Fan conducts with less than a few ohms.
YN
Repair the open circuit or short circuit.
Replace the Fuser Fan (PL 4.2).
Measure the voltage between the MCU PWB P/J408-1 (+) and GND (-) (BSD 10.2 Flag 4).
The voltage is approx. 0VDC.
YN
Check the wire between the MCU PWB and the Fuser Fan for an open circuit or a short
circuit (BSD 10.2 Flag 1/Flag 2/Flag 3/Flag 4).
The wire conducts with less than a few
ohms.
YN
Repair the open circuit or short circuit.
Replace the Fuser Fan (PL 4.2).
Replace the MCU PWB (PL 9.1).

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
