Status Indicator Raps
077-305 Tray Module Left Hand Cover Interlock Open RAP
BSD-ON:1.4
• The 2TM Cover is open.
• The TTM Cover is open.
Initial Actions
• Power OFF/ON
• Opening/closing of the Left Cover of the 2TM or TTM.
Procedure
Check opening/closing of the Left Cover of the 2TM or TTM. The Left Cover of the 2TM or
TTM can be opened/closed.
YN
Reinstall the Left Cover of the 2TM or TTM (PL 12.4/PL 13.7).
Check the installation of the Tray Module Interlock Switch. The Tray Module interlock Switch
is installed correctly.
YN
Install the Tray Module interlock Switch (PL 12.4/PL 13.7) correctly.
Execute Component Control [071-301 Tray Module Left Cover Interlock Switch]. Open and
close the Left Cover of the 2TM or TTM.
The display changes.
YN
Check the connections of P/J554, FS812 and FS813. P/J554, FS812 and FS813 are
connected correctly.
YN
Connect P/J554, FS812 and FS813.
Check the wire between J554-2 and FS812, and between J554-1 and FS813 for an open
circuit or a short circuit (BSD 1.4 Flag 3/Flag 4).
The wires between J554-2 and FS812,
and between J554-1 and FS813 are conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Tray Module Left Cover Interlock Switch (PL 12.4/PL 13.7)
between FS813 and FS812 (BSD 1.4 Flag 3/Flag 4).
The wire between FS813 and
FS812 is connecting successfully when the 2TM Cover or TTM Cover is closed, and
is insulated when the cover is open.
YN
Replace the Tray Module Left Cover Interlock Switch (PL 12.4/PL 13.7).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
077-307 DUP Cover Open RAP
BSD-ON:1.4
The DUP Cover is open.
Initial Actions
• Power OFF/ON
• Opening/closing of the DUP Cover.
Procedure
Check opening/closing of the DUP Cover. The DUP Cover can be opened/closed.
YN
Reinstall the DUP Cover.
Check the installation of the Duplex Open Switch (PL 8.1). The Duplex Open Switch is
installed correctly.
YN
Install the Duplex Open Switch (PL 8.1) correctly.
Execute Component Control [071-305 Duplex Open Switch]. Open and close the DUP
Cover. The display changes.
YN
Check the connections of P/J124 and P/J541. P/J124 and P/J541 are connected cor-
rectly.
YN
Connect P/J124 and P/J541.
Check the wire between J124 and J541 for an open circuit or a short circuit (BSD 1.4 Flag
5/Flag 6).
The wire between J124 and J541 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Duplex Open Switch (PL 8.1) between J541-4 and J541-5
(BSD 1.4 Flag 5/Flag 6).
The wire between J541-4 and J541-5 is connecting success-
fully when the DUP Cover is closed, and is insulated when the cover is open.
YN
Replace the Duplex Open Switch (PL 8.1).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
