Xerox WorkCentre 5222 User Manual

February, 2008
6-154
WorkCentre 5225, 5230
Product Specs., Common Tools
Launch Version
General Procedures
IIT/DADF Specifications
Common Tools
Table 4 DADF Specifications
Document Size: Platen Max size: 297 x 420 mm, 11 x 17 in.
Max scannable area: 297 x 420 mm
Document Size: DADF 5.5” x 8.5” (A5) LEF to 11” x 17” SEF (A3)
Max: 297 x 432 mm
Min: 139.7 x 210 mm
Document Weight: DADF Min: 50 gsm/16lb
Max: 128 gsm/32lb (Duplex mode)
Document Capacity: DADF 50 sheets 38 gsm to 120 gsm.
R/E Capability: Variable Percentages: 25% to 400% in 1% increments
Preset Percentages:
• 25%
• 50%
• 64.7% (11 x17 in. to 8.5 x 11 in.)
• 78.5% (8.5 x 14 in. to 8.5 x 11 in.)
• 100%
• 129.4% (8.5 x 11 in. to 11 x17 in.)
• 220% (3.5 x 5 in. to 8.5 x 11 in.)
• 400%
Presets can be changed in Tools mode.
Table 1 Common Tools
Description Part Number
Screw Driver (-) 3 x 50 600T 40205
Screw Driver (+) 6 x 100 600T 01989
Screw Driver (+) NO.1 499T 00356
Stubby Driver (+) (-) 600T 40210
Screw Driver (-) 100MM 499T 00355
Spanner and Wrench 5.5 x 5.5 600T 40501
Spanner and Wrench 7x 7 600T 40502
Hex Key Set 600T 02002
Box Driver 5.5MM 600T 01988
Side Cutting Nipper 600T 40903
Round Nose Pliers 600T 40901
Digital Multi-meter Set 600T 02020
Interlock Cheater 600T 91616
Silver Scale 150MM 600T 41503
CE Tool Case 600T 01901
Magnetic Screw Pick-up Tool 600T 41911
Scriber Tool 600T 41913
Magnetic pickup 600T 41911
Loupe 600T 42008
Flash Light 600T 01824
Brush 600T 41901
Tester Lead Wire (red) 600T 09583
Tester Lead Wire (black) 600T 02030

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
