February, 2008
2-137
WorkCentre 5225, 5230
012-268, 012-269
Status Indicator Raps
Launch Version
012-268 Booklet Rear Stapler Fail
BSD-ON:12.27
Booklet Stapler Assembly (Rear), cannot clinch properly; Booklet Rear Staple Home Switch
detected not to turn on (return to Home position could not be completed) within designated
time period after starting reverse motion.
Procedure
Execute Component Control[012-026 Rear Staple Motor (FWD) and 012-027 Rear Staple
Motor (REV)] alternately.
The motor energizes.
YN
Check the connections of P/J8895, P/J8893 and P/J8995. P/J8895, P/J8893 and P/
J8995 are connected correctly.
YN
Connect P/J8895, P/J8893 and P/J8995.
Check the wire between J8895 and J8995 for an open circuit or a short circuit (BSD
12.27).
The wire between J8895 and J8995 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Booklet PWB of each P8995-8/9/10/11 (+) and GND (-)
(BSD 12.27).
The voltage is approx. +24VDC.
YN
Replace the Booklet PWB (PL 23.21).
Replace the Finisher PWB (PL 23.16).
Select Stop. Select [013-142 Rear Staple Home Switch] Select Start. Actuate the Rear Staple
Home Switch. The display changes.
YN
Check the connections of P/J8895, P/J8893 and P/J8995. P/J8895, P/J8893 and P/
J8995 are connected correctly.
YN
Connect P/J8895, P/J8893 and P/J8995.
Check the wire between J8895 and J8995 for an open circuit or a short circuit (BSD
12.27).
The wire between J8895 and J8995 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Booklet PWB P8995-12 (+) and GND (-) (BSD 12.27).
The voltage is approx. +5VDC.
YN
Replace the Booklet PWB (PL 23.21).
Replace the Finisher PWB (PL 23.16).
Select Stop. If the problem continues, replace the Finisher PWB (PL 23.16).
012-269 Booklet Sub-CPU Communications Fail
Communications between the Finisher PWB and the Booklet PWB Failed
Initial Actions
• Check the connectors at the Finisher PWB and the Booklet PWB are connected or seated
properly
• Check the wiring between the Finisher PWB and the Booklet PWB for damage
Procedure
Power OFF and Power ON the Printer.
The problem is resolved.
YN
Reload the Software. The problem is resolved.
YN
Replace the Finisher PWB (PL 23.16). If the problem continues, replace the Booklet
PWB (PL 23.21).
Rerun the job.
Rerun the job.
