February, 2008
2-101
WorkCentre 5225, 5230
012-151 (A-Finisher), 012-152 (A-Finisher)
Status Indicator Raps
Launch Version
YN
Go to Wirenet A-Finisher +24VDC and check the +24VDC circuit. If the circuit is OK,
replace the Finisher PWB (PL 22.7).
Enter [012-013], measure the voltage between Finisher PWB J8705-2 (+) and GND (-).
The voltage changes.
YN
Replace the Finisher PWB (PL 22.7).
Replace the Sub Paddle Solenoid (PL 22.3).
Check the wires and connectors for an intermittent open or short circuit. If the problem contin-
ues, replace the Finisher PWB (PL 22.7).
012-152 (A-Finisher) Compiler Exit Sensor ON Jam
BSD-ON:12.3
The Compile Exit Sensor does not turn On within a specified time after receiving the Sheet Exit
command (the paper to be ejected has turned On the IOT Exit Sensor 1).
Initial Actions
• Check the Compile Exit Sensor is properly installed and free from foreign objects and that
the actuator is not broken.
• Power Off/On.
Procedure
Check the specifications of paper. Paper is in spec.
YN
Replace the paper with new paper that is ins spec.
Check the condition of the paper. The paper is in normal condition without any problem
that causes the paper to be bent or caught.
YN
Resolve any problem that causes the paper to be bent or caught.
Check the transport path for a foreign object, deformed part, and paper dust. The transport
path is in normal condition with no foreign object, deformed part and paper dust.
YN
Repair the deformed part(s) and remove the foreign object(s) and paper dust.
Check the Transport Roll for wear, deterioration and paper dust. The Transport Roll is in
normal condition.
YN
Remove the paper dust and replace the worn or deteriorated Transport Roll.
Check the drive mechanism to the Transport Roll for a deformed parts, broken parts, and/or
belt damage.
The drive mechanism free from defects.
YN
Repair defects or damage to the drive mechanism.
Check that the Finisher is installed properly. The Finisher is properly installed and properly
connected to the IOT.
YN
Reinstall the Finisher properly.
Enter Component Control [012-150]. Actuate the Compile Exit Sensor. The display changes.
YN
Check the connections of P/J8709 and P/J8728. P/J8709 and P/J8728 are securely
connected.
YN
Connect P/J8709 and P/J8728 securely.
Check for an open or short circuit between J8709 and J8728. The wires between J
8709 and J8728 are OK.
B
A
To Next Page
