WorkCentre 5225, 5230
012-260, 012-263
Status Indicator Raps
Launch Version
Check the wire between J8878 and J8983 for an open circuit or a short circuit (BSD
12.22).
The wire between J8878 and J8983 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Eject Motor (PL 22.9) between each point of J8878-1/3/4/6
(BSD 12.22).
The resistance is approx. 2Ohm.
YN
Replace the Eject Motor (PL 22.9).
Measure the voltage between the Finisher PWB (PL 23.16) P8983-5/6/7/8 (+) and GND (-
) (BSD 12.22).
The voltage is approx. +24VDC.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Eject Motor (PL 22.9). If the problem persists, replace the Finisher PWB (PL
23.16).
Replace the Finisher PWB (PL 23.16).
012-263 Rear Tamper Failure RAP
BSD-ON:12.19
After the Rear Tamper started moving to the home position, the Rear Tamper Home Sensor did
not turn On within 800ms.
Initial Actions
Power OFF/ON
Remove foreign substances in the Compiler Tray.
Procedure
Manually operate the Tamper mechanism. The Tamper mechanism moves smoothly.
YN
Replace the parts that are interfering with operation.
Execute Component Control[012-221 Rear Tamper Home Sensor]. Actuate the Rear Tamper
Home Sensor with paper.
The display changes.
YN
Check the connections of J8882 and J8984. J8882 and J8984 are connected cor-
rectly.
YN
Connect J8882 and J8984.
Check the wire between J8882 and J8984 for an open circuit or a short circuit (BSD 12.
The wire between J8882 and J8984 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8984-9 (+) and GND (-) (BSD 12.19).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8984-8 (+) and GND (-) (BSD 12.19).
Actuate the Rear Tamper Home Sensor with paper. The voltage changes.
YN
Replace the Rear Tamper Home Sensor (PL 23.12).
Replace the Finisher PWB (PL 23.16).
Alternately execute Component Control[012-026 Rear Tamper Motor FRONT ON] and Compo-
nent Control[012-029 Rear Tamper Motor REAR ON]. The Rear Tamper Motor starts up.
YN
Check the connections of P/J8883 and J8984. P/J8883 and J8984 are connected
correctly.
YN
Connect P/J8883 and J8984.
