Xerox WorkCentre 5222 User Manual

February, 2008
2-717
WorkCentre 5225, 5230
OF 1, OF 2
Status Indicator Raps
Launch Version
OF 1 Paper Size Mismatch In Width RAP
The width of the paper size is incorrect.
Initial Actions
• Power OFF/ON
• Reload the tray.
Procedure
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Feed paper from another tray. The problem occurs when paper is fed from another tray.
YN
Check the guide. The guide is set correctly.
YN
Set the guide correctly.
Check the operation of the Guide Actuator. The Guide Actuator works.
YN
Set the guide correctly.
Check the installation of the relevant Paper Size Switch. The relevant Paper Size
Switch is installed correctly.
YN
Install the relevant Paper Size Switch (PL 2.1/PL 12.1/PL 13.1) correctly.
Go to the OF 2 (SIZE SWITCH ASSY RAP).
Replace the MCU PWB (PL 9.1).
OF 2 Size Switch Assy RAP
Procedure
Manually activate the switches of the relevant Size Sensor. The relevant switches move
smoothly.
YN
Replace the relevant Size Sensor.
Execute the following Diag.: Activate SW5 of the relevant Size Sensor.
Tray 1: Component Control [071-210 Tray 1 Size Switch-SW5]
Tray 2: Component Control [071-211 Tray 2 Size Switch-SW5]
Tray 3: Component Control [071-212 Tray 3 Size Switch-SW5]
Tray 4: Component Control [071-200 Tray 4 Size Switch-SW5]
The display changes.
YN
Check the connections of the following connectors:
Tray 1: P/J109, P/J412
Tray 2: P/J110, P/J412
Tray 3: P/J820, P/J548
Tray 4: P/J824, P/J548
The connectors are connected correctly.
YN
Connect the connectors.
Check the following harnesses for an open circuit or a short circuit.
Tray 1: Between J109 and J412
Tray 2: Between J110 and J412
Tray 3: Between J820 and J548
Tray 4: Between J824 and J548
The relevant harnesses are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the following points (+) and GND (-).
Tray 1: MCU PWB P412-4
A

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
