Xerox WorkCentre 5222 User Manual

February, 2008
2-317
WorkCentre 5225, 5230
024-977 (A-Finisher), 024-979 (A-Finisher)
Status Indicator Raps
Launch Version
024-977 (A-Finisher) Stapler Feed Ready Fail
BSD-ON:12.5
• In the operation of getting the Stapler head ready at initialization, Stapler Ready Sensor
ON was not detected until a specified number (13) of Head idle-stapling operations.
• Immediately before stapling, the Stapler Ready Sensor was Off.
Initial Actions
• Check that the Staple Assembly and the Cartridge are properly installed, not broken and
include no foreign objects.
• Power Off/On.
Procedure
Enter Component Control [012-243]. Remove and reinstall the Cartridge from/in the Staple
Assembly.
The display changes.
YN
Check the connections of P/J8701 and P/J8731. P/J8701 and P/J8731 are securely
connected.
YN
Connect P/J8701 and P/J8731 securely.
Check for an open or short circuit between J8701 and J8731. The wires between
J8701 and J8731 are OK.
YN
Repair the open or short circuit.
Measure the voltage between J8701-4 (+) on the Finisher PWB and GND (-). The volt-
age is approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between J8701-6 (+) on the Finisher PWB and GND (-). Remove
and reinstall the Cartridge from/in the Staple Assembly.
The voltage changes.
YN
Replace the Staple Assembly (PL 22.4).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Check the wires and connectors for an intermittent open or short circuit. If the problem contin-
ues, replace the Finisher PWB (PL 22.7).
024-979 (A-Finisher) Stapler Near Empty
BSD-ON:12.5
One of the following:
• At Power On, Low Staple Sensor ON was detected.
• Immediately before the start of the operation of closing the Stapler Head, Low Staple Sen-
sor ON was detected.
Initial Actions
• Check that the Front Cover can be opened and closed.
• Check that the Staple Assembly and the Cartridge are properly installed, not broken and
include no foreign objects.
• Power Off/On.
Procedure
Check what amount of staples remain in the Cartridge. The is enough staples remaining
run the stapler.
YN
Replace the Cartridge.
Run DC330[012-242].
Enter Component Control [012-252]. Remove and reinstall the Cartridge from/in the Staple
Assembly.
The display changes.
YN
Check the connections of P/J8701 and P/J8731. P/J8701 and P/J8731 are securely
connected.
YN
Connect P/J8701 and P/J8731 securely.
Check for an open or short circuit between J8701 and J8731. The wires between
J8701 and J8731 are OK.
YN
Repair the open or short circuit.
Measure the voltage between J8701-4 (+) on the Finisher PWB and GND (-). The volt-
age is approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between J8701-7 (+) on the Finisher PWB and GND (-). Remove
and reinstall the Cartridge from/in the Staple Assembly.
The voltage changes.
YN
Replace the Staple Assembly (PL 22.4).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Check the wires and connectors for an intermittent open or short circuit. If the problem contin-
ues, replace the Finisher PWB (PL 22.7).

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
