WorkCentre 5225, 5230
IOT NVM List, IIT NVM List
General Procedures
Launch Version
IIT NVM List
954-803 Tray4 Fifth and Sixth Digits of Feed Capacity (8 Dig-
its)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-803 Tray4 Third and Fourth Digits of Feed Capacity (8
Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-803 Tray4 First Two Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-804 HCF Last Two Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-804 HCF Fifth and Sixth Digits of Feed Capacity (8 Dig-
its)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-804 HCF Third and Fourth Digits of Feed Capacity (8
Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-804 HCF First Two Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-805 MSI Last Two Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-805 MSI Fifth and Sixth Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-805 MSI Third and Fourth Digits of Feed Capacity (8
Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-805 MSI First Two Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-807 Last Two Digits of Fuser Discharging Number (8
Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-807 Fifth and Sixth Digits of Fuser Discharging Number
(8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-807 Third and Fourth Digits of Fuser Discharging Num-
ber (8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-807 First Two Digits of Fuser Discharging Number (8
Digits)
0 0~3 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-808 Last Two Digits of the number of Sheets Reaching
BIAS transfer Roll (8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-808 Fifth and Sixth Digits of the number of Sheets
Reaching BIAS transfer Roll (8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-808 Third and Fourth Digits of the number of Sheets
Reaching BIAS transfer Roll (8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
954-808 First Two Digits of the number of Sheets Reaching
BIAS transfer Roll (8 Digits)
0 0~3 1 Only 0 clearance is possible in the write mode. (“0 clearance” means all byte changes to
0 at the same time.)
Table 15 HFSI
Chain-
Link Name Default Range 1 Count Remarks
