Xerox WorkCentre 5222 User Manual

February, 2008
2-555
WorkCentre 5225, 5230
077-308, 077-309
Status Indicator Raps
Launch Version
077-308 Left Hand HIGH Interlock Open RAP
BSD-ON:1.4
The L/H-H Cover is open.
Initial Actions
• Power OFF/ON
• Opening/closing of the IOT L/H-H Cover.
Procedure
Check opening/closing of the IOT L/H-H Cover. The IOT L/H-H Cover can be opened/
closed.
YN
Reinstall the IOT L/H-H Cover.
Check the installation of the Exit 2 Interlock Switch. The Exit 2 Interlock Switch is installed
correctly.
YN
Install the Exit 2 Interlock Switch correctly.
Execute Component Control [071-304 Exit 2 Interlock Switch]. Open/close the IOT L/H-H
Cover.
The display changes.
YN
Check the connections of P/J434, P/J116, P606, J606 and SJ1. The P/J434, P/J116,
P606, J606 and SJ1 are connected correctly.
YN
Connect P/J434, P/J116, P606, J606 and SJ1.
Check the wire between J434 and J116 for an open circuit or a short circuit (BSD 1.4 Flag
7/Flag 8).
The wire between J434 and J116 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Exit 2 Interlock Switch (PL 6.4) between J434-12 and J434-
13 (BSD 1.4 Flag 7/Flag 8).
The wire between J434-12 and J434-13 is connecting
successfully when the IOT L/H-H Cover is closed, and is insulated when the cover
is open.
YN
Replace the Exit 2 Interlock Switch (PL 6.4).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
077-309 Left Hand Low Interlock Open RAP
BSD-ON:1.4
The L/H Lower Cover is open.
Initial Actions
• Power OFF/ON
• Opening/closing the L/H Lower Cover.
Procedure
Check opening/closing of the L/H Lower Cover. The L/H Lower Cover can be opened/
closed.
YN
Reinstall the L/H Lower Cover (PL 2.5).
Check the installation of the L/H Lower Cover Interlock Switch. The L/H Lower Cover Inter-
lock Switch is installed correctly.
YN
Install the L/H Lower Cover Interlock Switch (PL 2.5) correctly.
Execute Component Control [071-302 L/H Lower Cover Interlock Switch]. Open/close the L/H
Lower Cover.
The display changes.
YN
Check the connections of P/J106 and P/J410. P/J106 and P/J410 are connected cor-
rectly.
YN
Connect P/J106 and P/J410.
Check the wire between J106 and J410 for an open circuit or a short circuit (BSD 1.4 Flag
1/Flag 2).
The wire between J106 and J410 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the L/H Lower Cover Interlock Switch (PL 2.5) between J410-11
and J410-12 (BSD 1.4 Flag 1/Flag 2).
The wire between J410-11 and J410-12 is con-
necting successfully when the L/H Lower Cover is closed, and is insulated when
the cover is open.
YN
Replace the L/H Lower Cover Interlock Switch (PL 2.5).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
