Xerox WorkCentre 5222 User Manual

February, 2008
2-139
WorkCentre 5225, 5230
012-283
Status Indicator Raps
Launch Version
012-283 Set Clamp Home Sensor On Failure RAP
BSD-ON:12.23
After the Set Clamp started operation, the Set Clamp Home Sensor did not turn On within
200ms.
Initial Actions
• Power OFF/ON
• Remove foreign substances in the Eject Clamp mechanism.
Procedure
Manually operate the Eject mechanism. The Eject mechanism moves smoothly.
YN
Replace the parts that are interfering with operation.
Execute Component Control[012-251 Set Clamp Home Sensor]. Actuate the Eject Clamp
Home Sensor with paper. The display changes.
YN
Check the connections of J8871 and P/J8988. J8871 and P/J8988 are connected
correctly.
YN
Connect J8871 and P/J8988.
Check the wire between J8871 and J8988 for an open circuit or a short circuit (BSD
12.22).
The wire between J8871 and J8988 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8988-12 (+) and GND (-) (BSD 12.22).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8988-11 (+) and GND (-) (BSD 12.22).
Actuate the Eject Clamp Home Sensor with paper. The voltage changes.
YN
Replace the Eject Clamp Home Sensor (PL 23.11).
Replace the Finisher PWB (PL 23.16).
Alternately execute Component Control[012-054 Eject Motor FWD LO] and Component Con-
trol[012-055 Eject Motor FWD HI]. The Eject Motor (PL 22.9) starts up.
YN
Check the connections of P/J8878 and P/J8983. P/J8878 and P/J8983 are con-
nected correctly.
YN
Connect P/J8878 and P/J8983.
Check the wire between J8878 and J8983 for an open circuit or a short circuit (BSD
12.22).
The wire between J8878 and J8983 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Eject Motor (PL 22.9) between each point of J8878-1/3/4/6
(BSD 12.22).
The resistance is approx. 2Ohm.
YN
Replace the Eject Motor (PL 22.9).
Measure the voltage between the Finisher PWB (PL 23.16) P8983-5/6/7/8 (+) and GND (-
) (BSD 12.22).
The voltage is approx. +24VDC.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Eject Motor (PL 22.9). If the problem persists, replace the Finisher PWB (PL
23.16).
Replace the Finisher PWB (PL 23.16).
A
A
B
B

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
