Xinje DS3 Series User Manual

33
n.x□xx
Stop bit
2
0：2 bits, 2：1 bit
Servo OFF
n.□xxx
Parity bit
2
0～2
0:no parity, 1: odd parity, 2: even
parity
Servo OFF
Note: data bit cannot be changed, it is 8 bits.
 RS-485 port
DS3E series
CN1: port definition at drive
side
No.
Name
CN1-2
A
CN1-3
B
1. The fieldbus module is necessary to connect to CN1 to
perform X-NET fieldbus function. The module cannot
hot plug. Please use Profibus cable to ensure the
communication reliability.
2. For Modbus-RTU communication.
Note: DS3L cannot support RS485 and fieldbus.
Communication parameters:
RS485 default communication parameters: baud rate 19200bps, data bit 8, stop bit 1, even parity,
Modbus station no.1.
The Modbus station no. can be set through P7-00:
Parameter
Function
Default value
Range
Effective time
P7-00
Modbus station no.
1
0～255
Servo OFF
The communication parameters can be set through P7-01:
Parameter
Function
Default value
Range
Effective
time
n.xx□□
Baud rate
06
00～10
00：300
01：600
02：1200
03：2400
04：4800
05：9600
06：19200
07：38400
08：57600
09：115200
0A：192000
0B：256000
0C：288000
0D：384000
0E：512000
0F：576000
10：768000
11：1M
12：2M
13：3M
14：4M
15：5M
16：6M
Servo OFF
n.x□xx
Stop bit
2
0：2 bits, 2：1 bit
Servo OFF
1
5
9
6
