106 Chapter 11—Channel Library & View
03D—Owner’s Manual
Recalling Channel Programs
Channel programs are recalled from the Channel Library page.
1. Use the [VIEW] button to locate the Library page.
2. Use the PARAMETER wheel to scroll through the list of channel programs.
If you are using a mouse, position the mouse cursor over the parameter
box, press and hold the left mouse button, and then drag the mouse.
Channel programs that do not contain data have the title No Data! As each program is
selected, details of the channel data stored are displayed in the adjacent window.
STORED FROM—This shows which channel’s data is stored in the
program.
PAN MODE—This shows the pan mode of the channel program.
AUX CONFIG—This shows the aux send configuration of the chan-
nel program.
If the selected channel program’s data conflicts with the currently
selected channel, for example, STORED FROM shows an input
channel but the currently selected channel is BUS 1, CONFLICT
appears and a warning triangle appears next to the conflicting data.
There are four types of channel data.
Channel programs of the same type as the currently selected channel can be recalled.
For example, a channel program containing input channel 1 data can be recalled to the
stereo input channel. But a channel program containing aux send 1 data cannot be
recalled to a bus out.
When a mono channel program is recalled to a stereo channel (i.e., stereo input chan-
nel, an effects return channel, or input channels configured as a stereo pair), the left and
right pan controls of the stereo channel are set the same as the mono input channel’s
pan. When a stereo channel program is recalled to a single odd-numbered channel, that
channel is set the same as the program’s left channel pan. In the case of an even-num-
bered channel, pan is set the same as the program’s right channel pan.
3. Use the cursor button to select the RECALL switch, and then press the
[ENTER] button.
If you are using a mouse, simply click the RECALL switch.
The channel program is recalled.
Type Data
Type 1
Input channels 1 to 24, stereo input channel, effects returns channels
Type 2
Aux send channels
Type 3
Bus out channels
Type 4
Stereo out channel
To Next Page
