Channel Specs 259
03D—Owner’s Manual
Channel Specs
Mono input channel channels 1 to 24 (channels 17 to 24: YGDAI card)
Analog section
PHANTOM switch +48 V, CH 1 to 8
GAIN control 44 dB (–16 to –60 dB), channel 1 to 8
30 dB (+10 to –20 dB), channel 9 to 16
PAD switch 26 dB, channels 1 to 8
INSERT channel 1 & 2
AD convertor 20-bit linear 64-times oversampling
Digital section
Attenuator 0 to –96 dB 1 dB step
Delay Delay/Slap/Echo (Delay time: 0 to 200 ms, fs=48 kHz)
Pre/Post AUX1, AUX2, AUX3, AUX4, EFFECT1, EFFECT2
Phase Normal/Reverse
Equalizer 4-band parametric equalizer
Dynamics
ON button ON/OFF CH 1 to 16
Fader 60 mm stroke motorized fader CH 1 to 16
Solo ON/OFF
AFL/PFL
Pan
Bus assign BUS1, BUS2, BUS3, BUS4, STL·R
Direct out (channel 1 to 16: YGDAI)
Meter
Stereo input channel L·R
LCD
Analog section
GAIN control 30 dB (+10 to –20 dB)
AD convertor 20-bit linear 64-times oversampling
Digital section
FLIP switch Normal (ST IN: Analog)
FLIP (DIGITAL STEREO IN: Digital)
Attenuator 0 to –96 dB 1 dB step
Delay Delay/Slap/Echo (Delay time: 0 to 200 ms, fs=48 kHz)
Equalizer 4-band parametric equalizer
Dynamics
ON button ON/OFF
Fader 60 mm stroke motorized fader
Solo ON/OFF
AFL/PFL
Balance
Dual pan Individual/Gang/Inverted Gang
Bus assign BUS 1, BUS 2, BUS 3, BUS 4, ST L-R
Meter LCD
Pre/Post AUX1, AUX2, AUX3, AUX4, EFFECT1, EFFECT2
