Mixing Layer 31
03D—Owner’s Manual
Mixing Layer
The 03D [SEL] buttons, [ON] buttons, and faders are multifunction controls. Their
exact operation depends on the selected Mixing Layer. Fader operation is also affected
by the Fader modes. The operation of all these controls is shown in the following tables.
As these tables show, the ST IN, EFFECT RETURN, and ST OUT [SEL] buttons, [ON]
buttons, and faders are unaffected by the Mixing Layer setting.
SEL Buttons
With automix, [SEL] buttons are used to select channels for recording. See Automix on
page 175 for more information. [SEL] buttons are also used to select channels for the
fader and mute groups. See Groups & Pairs on page 111 for more information.
ON Buttons
When the [SOLO] function is on, input channels 1 to 24, the stereo input channel, and
effects returns channel’s [ON] buttons work as solo buttons, not mute buttons.
[ON] button operation is different in MIDI Remote mode. See MIDI Remote on page
243 for more information.
1. During automix recording, the EFFECT RETURN [SEL] button is used to turn effect edit-
ing on and off. In this case, the [EFFECT 1] and [EFFECT 2] buttons should be used to
select Effect 1 and Effect 2.
Mixing
Layer
SEL button
1–89–12 13–16 ST IN EFF RTN ST OUT
1–16
CH 1–8
select
CH 9–12
select
CH 13–16
select
ST IN
select
1
EFF RTN
1/2 select
ST OUT
select
17–24/
MASTER
CH 17–24
select
AUX 1–4
Master
select
BUS 1–4
Master
select
Mixing
Layer
ON button
1–89–12 13–16 ST IN EFF RTN ST OUT
1–16
CH 1–8
On/Off
CH 9–12
On/Off
CH 13–16
On/Off
ST IN
On/Off
EFF RTN 1/2
On/Off
ST OUT
On/Off
17–24/
MASTER
CH 17–24
On/Off
AUX 1–4
Master
On/Off
BUS 1–4
Master
On/Off
