Preset EQ Programs
# Title
Parameter
Description
LOW L-MID H-MID HIGH
01 Bass Drum 1
PEAKING PEAKING PEAKING H.SHELF
Emphasizes the low
range of a bass drum
and the attack created
by the beater.
G
+3.5 dB –3.5 dB 0.0 dB +4.0 dB
F
99 Hz 265 Hz 1.05 kHz 5.33 kHz
Q
1.2 10 0.9 —
02 Bass Drum 2
PEAKING PEAKING PEAKING LPF
Creates a peak around
80Hz, producing a
tight, stiff sound.
G
+8.0 dB –7.0 dB +6.0 dB ON
F
79 Hz 397 Hz 2.52 kHz 12.6 kHz
Q
1.4 4.5 2.2 —
03 Snare Drum 1
PEAKING PEAKING PEAKING H.SHELF
Emphasizes snapping
and rimshot sounds.
G
–0.5 dB 0.0 dB +3.0 dB +4.5 dB
F
132 Hz 1.00 kHz 3.17 kHz 5.04 kHz
Q
1.2 4.5 0.11 —
04 Snare Drum 2
L.SHELF PEAKING PEAKING PEAKING
Emphasizes the ranges
of that classic rock snare
drum sound.
G
+1.5 dB –8.5 dB +2.5 dB +4.0 dB
F
177 Hz 334 Hz 2.37 kHz 4.00 kHz
Q
— 10 0.7 0.1
05 Tom-tom 1
PEAKING PEAKING PEAKING PEAKING
Emphasizes the attack of
tom-toms, and creates a
long, “leathery” decay.
G
+2.0 dB –7.5 dB +2.0 dB +1.0 dB
F
210 Hz 667 Hz 4.49 kHz 6.35 kHz
Q
1.4 10 1.2 0.28
06 Cymbal
L.SHELF PEAKING PEAKING H.SHELF
Emphasizes the attack of
crash cymbals, extend-
ing the “sparkling”
decay.
G
–2.0 dB 0.0 dB 0.0 dB +3.0 dB
F
105 Hz 420 Hz 1.05 kHz 13.4 kHz
Q
— 8 0.9 —
07 High Hat
L.SHELF PEAKING PEAKING H.SHELF
Use on a tight high-hat,
emphasizing the mid to
high range.
G
–4.0 dB –2.5 dB +1.0 dB +0.5 dB
F
94 Hz 420 Hz 2.82 kHz 7.55 kHz
Q
— 0.5 1 —
08 Percussion
L.SHELF PEAKING PEAKING H.SHELF
Emphasizes the attack
and clarifies the
high-range of instru-
ments, such as shakers,
cabasas, and congas.
G
–4.5 dB 0.0 dB +2.0 dB 0.0 dB
F
99 Hz 397 Hz 2.82 kHz 16.9 kHz
Q
— 4.5 0.56 —
09 E.Bass 1
L.SHELF PEAKING PEAKING H.SHELF
Makes a tight electric
bass sound by cutting
very low frequencies.
G
–7.5 dB +4.5 dB +2.5 dB 0.0 dB
F
35 Hz 111 Hz 2.00 kHz 4.00 kHz
Q
— 5 4.5 —
10 E.Bass 2
PEAKING PEAKING PEAKING H.SHELF
Unlike program 9, this
program emphasizes
the low range of an
electric bass.
G
+3.0 dB 0.0 dB +2.5 dB +0.5 dB
F
111 Hz 111 Hz 2.24 kHz 4.00 kHz
Q
0.1 5 6.3 —
