Digital Inputs Specs 265
03D—Owner’s Manual
Digital Inputs Specs
Digital Outputs Specs
YGDAI Interface Card Specs
Control I/O Specs
1. De-emphasis is applied automatically if the input signal has been emphasized.
1. Channel status
Type: 2 channel audio signal
Emphasis: No
Sampling rate: depends on internal configuration
2. Channel status
Type: 2 channel audio signal
Category code: 2 channel PCM encoder/decoder
Copy prohibit: No
Emphasis: No
Clock accuracy: Level II (1,000 ppm)
Sampling rate: depends on internal configuration
3. Dither: wordlength 16–24 bit
1. TO HOST and TO EDITOR cannot be used at the same time.
Connection Format Data Length Level Connector
DIGITAL
STEREO IN
1
AES/EBU AES/EBU 24 bit RS-422 XLR-3-31 type
COAXIAL
IEC-958
Consumer Use
24 bit 0.5 Vpp (75Ω) Phono
Connection Format Data Length Level Connector
DIGITAL
STEREO OUT
AES/EBU
AES/EBU
1
24 bit
3
RS-422 XLR-3-32 type
COAXIAL
IEC-958
2
Consumer Use
20 bit
3
0.5 Vpp (75Ω) Phono
Card Format Inputs Outputs
CD8-AT
ADAT 8 inputs (CH17–24) 8 outputs (BUS, AUX, ST, CH direct)
CD8-TDII
TASCAM 8 inputs (CH17–24) 8 outputs (BUS, AUX, ST, CH direct)
CD8-AE-S
AES/EBU 8 inputs (CH17–24) 8 outputs (BUS, AUX, ST, CH direct)
CD8-Y
Yamaha 8 inputs (CH17–24) 8 outputs (BUS, AUX, ST, CH direct)
CD8-CS
Cascade Cascade inputs Cascade outputs
Connection Format Level Connector
TO HOST
1
——8-pin mini DIN
MIDI IN (MTC)
MIDI — 5-pin DIN
MIDI THRU
MIDI — 5-pin DIN
MIDI OUT
MIDI — 5-pin DIN
MOUSE
——9-pin D-sub (male)
TO EDITOR
1
— RS-422 9-pin D-sub (female)
WORD CLOCK IN
— TTL (75Ω ON/OFF) BNC
WORD CLOCK OUT
— TTL (75Ω) BNC
