Setting Aux Send Master Levels 93
03D—Owner’s Manual
Setting Aux Send Master Levels
Aux send master levels are controlled using faders 9 to 12. The function of
these faders depends on the selected Mixing Layer. See Faders on page 32 for
more information.
1.Use the [MIXING LAYER] button to select the 17–24/MASTER
Mixing Layer.
Faders 9 to 12 now function as aux send master level controls.
2.Use faders 9 to 12 to adjust the aux send levels.
When aux sends are configured as a stereo pair using the Pair function (Stereo Pairs on
page 114), the faders of the two sends work together, and either fader can be used to
adjust the aux send master level.
Muting Aux Sends
Aux sends can be muted using [ON] buttons 9 to 12. These buttons contain
indicators that light up when an aux send is on.
1. Use the [MIXING LAYER] button to select the 17–24/MASTER Mixing
Layer.
[ON] buttons 9 to 12 now function as aux send mute switches.
2. Press the [ON] buttons.
Press the [ON] button again to unmute an aux send.
When aux sends are configured as a stereo pair using the Pair function (Stereo Pairs on
page 114), the [ON] buttons of the two sends work together, and either button can be
used to mute the aux send masters.
Applying EQ to Aux Sends
Each aux send features four-band parametric EQ. See EQ on page 45 for more infor-
mation.
Aux Send Dynamics Processors
Each aux send features a dynamics processor. See Dynamics Processors on page 143 for
more information.
6
0
5
10
20
40
60
00
ON
