1 - 2 ET5X User Guide
Features
Figure 1-1 Front View
Table 1-1 Front View
Item Description
1 Ambient Light Sensor - Recognizes the ambient light and adjusts the display brightness (if
enabled).
2 Front Microphone - Use for voice communications.
3 Front Facing Camera - Use for video conferencing.
4 Camera Indicator LED - Lights red when the camera is activate. Momentarily lights red when the
device boots and shuts down.
5 Charging Indicator LED - Indicates charging status.
•
OFF - device is not connected to charger.
•
ORANGE - device is charging.
•
GREEN - device is connected and fully charged.
•
RED - charge error.
6 Windows Button - Press to launch the Windows Start screen.
134
6
2 5
5
8” Version
10” Version
