Getting Started 4 - 3
Figure 4-1 Bar Code Scanning with Expansion Back with SE4750
4. Press and hold the Scan button.
The red laser aiming pattern turns on to assist in aiming. Ensure the bar code is within the area formed by the
cross-hairs in the aiming pattern. The aiming dot is used for increased visibility in bright lighting conditions.
The Expansion Back beeps to indicate the bar code was decoded successfully.
Figure 4-2 SE4750 Expansion Back Aiming Pattern
5. Release the Scan button. The bar code data displays on the screen.
Using the SE4710 Expansion Back
To read a bar code, a scan-enabled application is required.
1. Launch a scanning application.
2. Point the Expansion Back exit window at a bar code.

Zebra ET5X Specifications

General

Brand	Zebra
Model	ET5X
Category	Tablet
Language	English
