Scanning Sequence Examples
In most cases scanning one bar code sets the parameter value. For example, to set the beeper tone to high,
scan the High Frequency (beeper tone) bar code listed under Beeper Tone on page 7-7. The linear imager
issues a fast warble beep and the LED turns green, signifying a successful parameter entry.
Other parameters require scanning several bar codes. See these parameter descriptions for this procedure.
Errors While Scanning
Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.
User Preferences/Miscellaneous Option Parameter Defaults
Table 7-1 lists the defaults for preferences parameters. To change the default values:
• Scan the appropriate bar codes in this guide. These new values replace the standard default values in
memory. To recall the default parameter values, scan the Default Parameters on page 7-4.
• Configure the linear imager using the 123Scan
2
configuration program (see 123SCAN2 on page 9-1).
Table 7-1 User Preferences Parameter Defaults
NOTE See Appendix A, STANDARD DEFAULT PARAMETERS for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Parameter
Parameter
Number
Default
Page
Number
User Preferences
Set Default Parameter n/a Set Factory Defaults 7-4
Report Version n/a n/a 7-5
Parameter Bar Code Scanning 236 Enable 7-5
Beep After Good Decode 56 Enable 7-6
Decode Illumination Indicator 859 Disable 7-6
Beeper Tone 145 Medium 7-7
Beeper Volume 140 High 7-8
Beeper Duration 628 Medium 7-8
Suppress Power Up Beeps 721 Do Not Suppress (Disable) 7-9
Hand-Held Trigger Mode 138 Level 7-9
Hands-Free (Presentation) Trigger Mode 630 Enable 7-10
Linear Imager Picklist Mode 1211 Auto-discriminate 7-11
Aiming Illumination 1187 Pulsing Pattern 7-12

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
