7 - 22 LI2208 PRODUCT REFERENCE GUIDE
Scan Data Transmission Format
Parameter # 235
To change the scan data format, scan one of the eight bar codes corresponding to the desired format (bar
codes begin on page 7-23). To set the values for a prefix or suffix follow the instructions in Prefix/Suffix Values
on page 7-21.
NOTE If using this parameter do not use ADF rules to set the prefix/suffix.
Table 7-2 Scan Data Format Descriptions
Scan Data Format Description
Data As Is Sends data to the host as is (with no format changes).
<DATA> <SUFFIX 1> Sends scanned data to the host with one suffix value appended to the
end of the scanned data. The suffix 1 value is set in
Prefix/Suffix
Values on page 7-21.
<DATA> <SUFFIX 2> Sends scanned data to the host with one suffix value appended to the
end of the scanned data. The suffix 2 value is set in
Prefix/Suffix
Values on page 7-21.
Note : Suffix 1 (above) and Suffix 2, used individually as single
appendages to the end of the scanned data, are virtually performing
the same function - appending one suffix to the end of scanned data
transmitted to the host.
<DATA> <SUFFIX 1> <SUFFIX 2> Sends scanned data to the host with two suffix values appended to
the end of the scanned data. The values for each suffix are set in
Prefix/Suffix Values on page 7-21.
<PREFIX> <DATA > Sends scanned data to the host with one prefix value appended to
the front of the scanned data. The prefix value is set in
Prefix/Suffix
Values on page 7-21.
<PREFIX> <DATA> <SUFFIX 1> Sends scanned data to the host with one prefix value appended to
the front of the scanned data, and one suffix value appended to the
end of the scanned data. Both prefix and suffix values are set in
Prefix/Suffix Values on page 7-21.
<PREFIX> <DATA> <SUFFIX 2> Sends scanned data to the host with one prefix value appended to
the front of the scanned data, and one suffix value appended to the
end of the scanned data. Both prefix and suffix values are set in
Prefix/Suffix Values on page 7-21.
Note : Suffix 1 and Suffix 2, used individually as single appendages to
the end of the scanned data, are virtually performing the same
function - appending one suffix to the end of scanned data
transmitted to the host.
<PREFIX> <DATA> <SUFFIX 1> <SUFFIX 2> Sends scanned data to the host with one prefix value appended to
the front of the scanned data, and two suffix values appended to the
end of the scanned data, in the order shown: suffix 1 followed by
suffix 2. Both prefix and suffix values are set in
Prefix/Suffix Values
on page 7-21.

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
