Zebra LI2208 User Manual

CHAPTER 1 GETTING STARTED
Introduction
The LI2208 represents the next generation in 1D scanning and builds on our most popular scanner ever, the
LS2208. You get the same reliability and ergonomics of the LS2208, combined with enhanced features such as
extended range and support for mobile bar codes. With our best-in-class linear imager, you can count on
unparalleled scanning performance on every bar code, every time.
Unpacking
Remove the scanner from their respective packing and inspect for damage. If the scanner was damaged in
transit, contact Zebra Global Customer Support Center. See page xvii for contact information. KEEP THE
PACKING. It is the approved shipping container and should be used if the equipment ever needs to be
returned for servicing.

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
