Zebra LI2208 User Manual

USER PREFERENCES & MISCELLANEOUS SCANNER OPTIONS 7 - 17
Continuous Bar Code Read
Parameter # 649
Enable Continuous Bar Code Read to report every bar code while the trigger is pressed.
Unique Bar Code Reporting
Parameter # 723
Enable Continuous Bar Code Read Uniqueness to report only unique bar codes while the trigger is pressed.
This option only applies when
Continuous Bar Code Read is enabled.
*Disable Continuous Bar Code Read
(0h)
Enable Continuous Bar Code Read
(1h)
Disable Continuous Bar Code Read Uniqueness
(00h)
*Enable Continuous Bar Code Read Uniqueness
(01h)

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
