7 - 26 LI2208 PRODUCT REFERENCE GUIDE
Unsolicited Heartbeat Interval
Parameter # 1118
The linear imager supports sending Unsolicited Heartbeat Messages to assist in diagnostics. To enable this
feature and set the desired unsolicited heartbeat interval, scan one of the time interval bar codes below, or
scan Set Another Interval followed by four numeric bar codes from Appendix H, NUMERIC BAR CODES
(scan sequential numbers that correspond to the desired number of seconds).
Scan Disable Unsolicited Heartbeat Interval to turn off the feature.
The heartbeat event is sent as decode data (with no decode beep) in the form of:
MOTEVTHB:nnn
where nnn is a three digit sequence number starting at 001 and wrapping after 100.
NOTE For correct operation, you must disable Low Power Mode (see Low Power Mode on page 7-12).
10 seconds
1 minute
Set Another Interval
*Disable Unsolicited Heartbeat Interval

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
