Zebra LI2208 User Manual

B - 2 LI2208 PRODUCT REFERENCE GUIDE
USB and Keyboard Wedge Country Keyboard Types (Country Codes)
Scan the bar code corresponding to the keyboard type. For a USB host, this setting applies only to the USB
Keyboard (HID) device. If the keyboard type is not listed, see Emulate Keypad on page 3-9 for the USB HID
host. For a Keyboard Wedge host, see Alternate Numeric Keypad Emulation on page 6-6.
NOTE When changing USB country keyboard types the linear imager automatically resets. The linear imager
issues the standard startup beep sequences.
IMPORTANT 1. Some country keyboard bar code types are specific to certain Windows Operating Systems (i.e.,
XP, and Win 7, or higher). Bar codes requiring a specific Windows OS are noted so in their bar
code captions.
2. Use the French International bar code for Belgian French keyboards.
*US English (North American)
Albanian
Arabic (101)
Arabic (102)
Arabic (102) AZERTY

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
