Zebra LI2208 User Manual

MAINTENANCE, TROUBLESHOOTING & TECHNICAL SPECIFICATIONS 11 - 7
Technical Specifications
Table 11-2 Technical Specifications - LI2208 Linear Imager
Item Description
Physical Characteristics
Dimensions 6.30 in. H x 2.64 in. W x 3.90 in. L
16 cm H x 6.7 cm W x 9.9 cm L
Weight 4.95 oz./140 grams
Color
Nova White, Healthcare White, or Twilight Black
Host Interface USB, RS-232, RS-485 (IBM), Keyboard Wedge (also see
Table 11-3 )
Voltage and Current 5VDC ± 10%
<165 mA scanning
<40 mA standby
<2.5 mA USB suspend
<4.0 mA low power mode (when enabled, RS232 and Keyboard Wedge
only)
Power Source Host power or external power supply
Keyboard Support Supports over 90
international keyboards
Performance Characteristics
Light Source LED Class 1 device 617nm (amber)
Scan Speed 547 scans per second
Scan Pattern Single bright aiming line
Scan Angle Horizontal 35°
Roll Tolerance ± 45°
Pitch Tolerance ± 65°
Skew Tolerance ± 65°
Nominal Working Distance (See
Decode Ranges on page 2-6 )
Decode Capability UPC/EAN: UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13,
Bookland EAN, Bookland ISBN Format, UCC Coupon Extended Code,
ISSN EAN Code 128 Including GS1-128, ISBT 128, ISBT Concatenation,
Code 39 including Trioptic Code 39, Convert Code 39 to Code 32 (Italian
Pharmacy Code), Code 39 Full ASCII Conversion Code 93 Code 11 Matrix 2
of 5 Interleaved 2 of 5 (ITF) Discrete 2 of 5 (DTF) Codabar (NW - 7) MSI
Chinese 2 of 5 IATA Inverse 1D (except all GS1 DataBars) GS1 DataBar
including GS1 DataBar-14, GS1 DataBar Limited, GS1 DataBar Expanded
Motion Tolerance 25 in./ 63.5 cm per second
Min. Print Contrast 15% MRD
User Environment
Ambient Light Immunity Max 108,000 lux
Operating Temperature 32° to 122° F (0° to 50° C)

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
