8 - 70 LI2208 PRODUCT REFERENCE GUIDE
UPC/EAN/Code 93 Security Level
Parameter # 77
The linear imager offers four levels of decode security for UPC/EAN, and Code 93. Select increasing levels of
security for decreasing levels of bar code quality. There is an inverse relationship between security and linear
imager aggressiveness, so choose only that level of security necessary for any given application.
• UPC/EAN Security Level 0: This setting allows the linear imager to operate in its most aggressive state,
while providing sufficient security in decoding most “in-spec” bar codes.
• UPC/EAN Security Level 1: This default setting eliminates most misdecodes.
• UPC/EAN Security Level 2: Select this option if Security level 1 fails to eliminate misdecodes.
• UPC/EAN Security Level 3: If you selected Security Level 2 and misdecodes still occur, select this
security level. Be advised, selecting this option is an extreme measure against mis-decoding severely
out of spec bar codes. Selecting this level of security significantly impairs the decoding ability of the
linear imager. If you need this level of security, try to improve the quality of the bar codes.
UPC/EAN/Code 93 Security Level 0
(00h)
*UPC/EAN/Code 93 Security Level 1
(01h)
UPC/EAN/Code 93 Security Level 2
(02h)
UPC/EAN/Code 93 Security Level 3
(03h)

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
