Zebra TC56 User Manual

6 - 2 TC56 User Guide for Android Version 6.0.1
A USB icon appears at the top of the screen, and the notification Connected as a media device or
Connected as a camera appears briefly at the top of the screen.
2. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
3. Touch More ....
4. Touch Tethering & portable hotspot.
5. Touch the USB tethering switch to enable.
The host computer is now sharing the TC56’s data connection.
To stop sharing the data connection, touch the USB tethering switch again or disconnect the USB cable.
Bluetooth Tethering
Use Bluetooth tethering to share the data connection with a host computer.
Configure the host computer to obtain its network connection using Bluetooth. For more information, see the host
computer’s documentation.
1. Pair the TC56 with the host computer.
2. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
3. Touch More ....
4. Touch Tethering & portable hotspot.
5. Touch the Bluetooth tethering switch to enable.
The host computer is now sharing the TC56’s data connection.
To stop sharing the data connection, touch the Bluetooth tethering switch again.
Portable Wi-Fi Hotspot
Configure the Wi-Fi Hotspot settings.
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch More ....
3. Touch Tethering & portable hotspot.
4. Touch the Portable Wi-Fi hotspot switch to enable.
After a moment, the TC56 starts broadcasting its Wi-Fi network name (SSID), so you can connect to it with up
to eight computers or other devices. The Hotspot icon appears in the Status Bar.
To stop sharing the data connection, touch the Portable Wi-Fi hotspot switch again.
Configuring the Wi-Fi Hotspot
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch More ....
3. Touch Tethering & portable hotspot.
4. Touch Set up Wi-Fi hotspot.

Zebra TC56 Specifications

General

Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	0.016 GB
Internal memory	0.002 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Processor family	Qualcomm
Processor frequency	1.8 GHz
Operating system version	6.0
Operating system installed	Android
RFID reader	-
Certification	WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Battery capacity	4300 mAh
Data network	CDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported	850, 1900 MHz
Second camera	No
Rear camera resolution (numeric)	13 MP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Height	18.6 mm
Weight	249 g
