Zebra TC56 User Manual

2 - 24 TC56 User Guide for Android Version 6.0.1
Transferring Files using Media Transfer Protocol
1. Connect the Rugged Charge/USB Cable to the TC56 or place the TC56 into the 1-Slot USB/Charge Only
Cradle. See Chapter 7, Accessories for setup information.
2. Pull down the Notification panel and touch USB for Charging.
Figure 2-20 Use USB Dialog Box
3. Touch File transfers.
4. On the host computer, open a file explorer application.
5. Locate the TC56 as a portable device.
6. Open the SD card or the Internal storage folder.
7. Copy files to and from the TC56 or delete files as required.
Transferring Files using Photo Transfer Protocol
1. Connect the Rugged Charge/USB Cable to the TC56 or place the TC56 into the 1-Slot USB/Charge Only
Cradle. See Chapter 7, Accessories for setup information.
2. Pull down the Notification panel and touch USB for Charging.
NOTE Use Media Transfer Protocol (MTP) to copy files between the TC56 (internal memory or microSD card)
and the host computer.
NOTE Use Photo Transfer Protocol (PTP) to copy photos from either the microSD card or internal memory to the
host computer.

Zebra TC56 Specifications

General

Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	0.016 GB
Internal memory	0.002 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Processor family	Qualcomm
Processor frequency	1.8 GHz
Operating system version	6.0
Operating system installed	Android
RFID reader	-
Certification	WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Battery capacity	4300 mAh
Data network	CDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported	850, 1900 MHz
Second camera	No
Rear camera resolution (numeric)	13 MP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Height	18.6 mm
Weight	249 g
